Hithium 280Ah 3.2V LiFePO4 Cells - Brand New Grade A with QR Code

Free Shipping & Free Tax

DDP Duty Free Delivery, the price includes shipping and VAT!

NOTE：Hithium 280Ah Cells are temporarily out of stock, the latest stock will arrive at EU warehouse around August 30th

Hithium 280Ah Testing Videos

Feature

• 100% Grade A Cells
• Deep Cycles, 10000 cycles life.
• Free Accessories: Connecting Strips, Nuts, Washers, etc.
• Highly automated production equipment to ensure battery consistency.
• Square aluminum shell structure, high-precision explosion-proof valve design, good safety performance.
• Low internal resistance, high discharge rate, and stable discharge platform.
• Green environment, ISO14000 approval, products meet GB and UN criteria, and ROHS compliant.

Specification

Cell Brand: HITHIUM

Cell Model: LFP71173207/280Ah

Chemistry: Lithium Iron Phosphate(LiFePO4 or LFP)

Nominal Voltage: 3.2V

Operational Voltage: 2.5V – 3.65V

Nominal Capacity: 280Ah

Typical Energy: 896 Wh

Impedance (1KHz): ≤0.18±0.05mΩ

Weight: 5.43±0.2kg

Dimensions (mm): 207.1±0.5*174.7±0.5*71.7±1mm

Terminal: M6 Laser Welding Stud

Cycle Performance: ≥7500 Cycles(0.5C/0.5C, 25±2°C, SOC≥70%)

Standard Charge/Discharge Current: 0.5C/0.5C

Standard Charge/Discharge Cut-off Voltage: 3.65V/2.5V

Max Continuous Charge/Discharge Current: 1C/1C

Recommended SOC window: 10%～90%

Residual Capacity loss: Per month≤3.0%

Operating Temperature (Charging): 0℃~60℃

Operating Temperature (Discharge): -30℃~60℃

Storage Temperature: -30~60°C

Available documents:

Hithium 280Ah LiFePO4 Cells Datasheet

Important Installation Notice:

To avoid contact resistance, the following points must be observed:

✔️ Thoroughly clean the battery terminals with ethanol or pure alcohol to remove oxide layers.
✔️ The terminals must not be touched with greasy fingers – they must be absolutely grease-free and clean.
✔️ Ideally, the contacts should be cleaned with a brass brush or fine sandpaper (grit 1000).
✔️ The contact surfaces of the cell connectors must also be carefully cleaned.
❌ The use of assembly greases, copper paste, or similar substances must be strictly avoided – they cause contact resistance, which can lead to heat generation and measurement errors during operation. As a result, the full capacity of the cells cannot be utilized.

🔧 Tighten the M6 screws with a torque of 6 Nm.

NOTE

1. One Cell will come with 1 busbar, 2 flange nuts for free. (e.g. 4 pcs Cells will come with 4 pcs busbars, 8 pcs flange nuts )
2. Each cell shall be used under the strict monitor, control, and protection by the BMS.
3. Before the first use, always charge the cells to full voltage.
4. We will match (capacity, voltage, resistance) all cells before delivery.
5. The battery is suitable for DIY lovers with experience.
6. The HITHIUM 280Ah LiFePo4 Cell has the same performance as CATL 3.2V 280Ah cells.

Warranty

The warranty period is 5 years from the date you receive.

We only replace new cell for free due to the failure of manufacturing.

Before the shipment, we will detect the cell voltage/resistance/appearance and other issues. we can only ensure that single cell is good before the shipment.

When arrival you can test the cells within 1 week, if you found problems please contact us for refund or replace. Any return behavior buyers need to be responsible for shipping fee.

Remark

Please read carefully all the description before taking orders, the battery is suitable for DIY lovers with experience, people who are not familiar with the safe use of lithium battery knowledge, please go to our shop to buy the finished product.

DIY battery pack must get the cells balanced (same voltage ) before assembly.
And we don’t accept refund for buyers who don’t know how to assembled or unbalanced assembly.

Please use the correct BMS during assembly. We don’t accept refund for the problem caused during assembly process or after the assembly. Such as not use the BMS, the BMS connected to the wrong wire lead to battery damage, charger failure, the assembly error or unbalanced assembly, etc.

Before assembling, please make sure use the same capacity cell and use the same brand of the cell. It is forbidden to mix cells with different capacity and brand in the same battery system. Otherwise, we will not be responsible for quality assurance.

Application
