Note :

3 types model when Ordering:

Please make sure to choose the correct model as we will ship according to your selection.

Free Shipping & TAX

Our current price is the final price, free shipping and tax, you don't need to pay any other fees.

Description

Nominal Capacity:	100Ah
Usable Capacity:	100Ah
Nominal Voltage:	25.6V
Energy:	2560Wh
Max.Continuous Load Power:	2560W
Charge Voltage:	29.2V
Charge Method:	CC/CV
Preferred Charger:	29.2V40A
Standard Charge Current:	20A
Max.Charge Current:	100A
Discharge Cut-Off Voltage:	20V
Standard Discharge Current:	20A
Max.Continuous Discharge Current:	100A
Max.Discharge Current (5 Seconds):	200A
Cycle Life:	4000~8000 times
Internal Impedance:	≤42mΩ
Dimension (in):	20.67*10.59*8.58in
Weight: Approx.	82.01lb/19.6kg
Working Temp. Range(Charge):	32℉-122℉/0℃～50℃(No Self-Heating)
Working Temp. Range(Discharge):	-4℉-140℉/-20℃～60℃(No Self-Heating)
Working Temp. Range(Charge):	-4°F-122°F/-20°C~50°C(Have Self-Heating)
Working Temp. Range(Charge):	-4°F-122°F/-20°C~50°C(Have Self-Heating)
Smart BMS	Have Bluetooth/No Bluetooth
Terminal Type:	M8
Water Dust Resistance:	IP65
Case Material:	ABS
CHARGING
Charging Limit Voltage:	29.2V
Over Voltage Disconnect:	30.0V
Over Voltage Reconnect:	28.4V
Balance Charging Voltage:	28.0V
Float Charing Voltage:	27.6V
Boost Charging Voltage:	27.6V
Boost Reconnect Charing Voltage:	26.2V
DISCHARGING
Low Volatage Disconnect:	21.6V
Low Voltage Reconnect:	24.8V
Under Voltage Warning:	23.2V
Under Voltage Warning Reconnect:	24.0V
Discharging Limit Voltage:	20.8V
Over Discharge Disconnect:	20.8V
Over Discharge Reconnect:	23.2V
Over Discharge Delay Time:	0.8S
